‎BHFI MB80-125X114

Name: BHFI MB80-125X114
Brand: ITSBORE
SKU: ISC4550028
Price: 20279.19 RMB
Availability: InStock

Fine boring heads with MB modular system connection and .00008″ direct diametric adjustment .

项# ISC4550028

品牌名称: Iscar

制造商号: 4550028

产品规格

Cutting Diameter Minimum (DCN)

1.417″

测量方式

Inch

Cutting Diameter Maximum (DCX)

19.685″

Rotational Speed Maximum (RPMX)

4000 rpm

Functional Length (LF)

2.48″

刀体材质

Steel

Body Diameter (BD)

4.921″

单位

Connection Diameter Machine Side (DCONMS)

3.15″

系列描述

Fine boring heads with MB modular system connection and .00008″ direct diametric adjustment .

COO

Italy

备注

点击一种规格，再点击“更多”可查看配件图

包装重量

12.6655
