产品规格
| Drill Bit Size / Cutting Diameter (DC) | 5.1 mm | 等级 | IC608 |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 5.1 mm | 测量方式 | Metric |
| 涂层 | AlTiCrSiN | Usable Length (LU) | 20 mm |
| 适用材料 | | 钢 | 不锈钢 | 铸铁 | 硬材料 | 高温合金 | | Length Chip Flute (LCF) | 29 mm |
| 应用 | | 钻削 | | Overall Length (OAL) | 66 mm |
| Connection Diameter Machine Side (DCONMS) | 6 mm | Cutting Direction (HAND) | Right Hand |
| Coolant Supply Property (CSP) | Coolant Thru | 刀体材质 | Carbide |
| Number of Teeth | 3 | Connection Code Machine Side (CCMS) | Cylindrical |
| Shank Length (LS) | 36 mm | Shank Diameter Tolerance (TCDMM) | h6 |
| 柄部形式 | Round | 单位 | M |
| 切削刃材质 | Carbide |
产品特性
| 系列描述 | 带内冷却通孔的三刃整体硬质合金钻头，钻深3xD | COO | Korea |
Shipping Info
包装重量
0.0230
