产品规格
| Shank Size (SS) | 40 | Connection Diameter Maximum Workpiece Side (DCONXWS) | 20 mm |
| Connection Size (CSI) | ER32 | 测量方式 | Metric |
| Body Diameter (BD) | 50 mm | 刀体材质 | Steel |
| Protruding Length (LPR) | 65 mm | Connection Code Machine Side (CCMS) | DIN69871 |
| Tool Type | DIN 69871 | 单位 | M |
| Connection Diameter Minimum Workpiece Side (DCONNWS) | 2 mm |
产品特性
| 系列描述 | 带DIN69871 ADB型锥柄的DIN6499 ER刀柄 | 系列名称 | DIN69871-ER (form ADB) |
| 备注 | B是带内冷设计的型号 | 品牌 | Iscar |
| COO | Turkey |
Shipping Info
包装重量
1.0810
名字
弹簧筒夹夹头
系列名称
DIN69871-ER (form ADB)
品牌
Iscar
